Inspection & Metrology

CMM-Verified Inspection on Every Part

IMT Precision operates a dedicated 500 sq. ft. climate-controlled inspection room independent from the production floor. Every tool is calibrated per ISO requirements, and every critical dimension is verified before parts ship. For programs that require First Article Inspection (FAI) reports, material traceability, or AS9102-format documentation, our quality team delivers complete data packages.

Equipment

Coordinate Measuring Machines

• Nikon Altera S 10.7.6 CNC CMM with CMM Manager — 40" x 28" x 24" capacity, volumetric accuracy from 1.8µm + L/400, repeatability from 1.7µm
• Mitutoyo Bright M707 with Geomeasure — 28" x 28" x 24" capacity, volumetric accuracy from 3.5µm + 4.0L/1000
• Faro Quantum M with CAM2 Measure — 13.1 ft reach in a sphere, single point accuracy ±0.0026", FAROBlu Laser Line Probe HD with full scanning

Optical & Surface Inspection

• Mitutoyo PH-3515 Optical Comparator — 14" screen, 10" x 4" travel, M2 Geometric 2D software, edge detection
• Taylor Hobson Surftronic 3 Profilometer

Leak Testing

• ASM 182T Helium Leak Detector — detectable leak rate <3×10⁻¹⁰ mbar·L/s, range 1×10⁻¹¹ to 1×10⁻¹ mbar·L/s

Supporting Equipment

• Granite surface plates: (1) 6' x 12' Starrett, (1) 4' x 8' Starrett, (3) 2' x 3' floor plates, (1) 24" x 36" plate
• Height gages: 24" digital, 24" dial, 40" dial
• 60" vernier calipers, 6" and 12" digital calipers, 24" digital calipers
• Pin gages (.011 to 1.000), (2) grade 2 81-pc gage block sets
• (2) 5" sine bars, micrometers (0"-18" carbide tip set, digital 0"-1", digital 1"-2")
• Thread gages, bevel protractors, chamfer gages, dial indicators, 1-2-3 blocks
